6061 Aluminium – T6 Heat Treated
CNC Parts
Custom Shaped Tubes
Internal Hose Routing
Handcrafted TIG Double Smooth Welding
Polished by Hand
Monocoque Full Carbon Fiber
Carbon 1.5′ Tapered Steerer Tube
Internal Hose Routing
15mm Thru Axle
Fender and Light Mounts
Pinion C1.9 i Smart Shift CDX Gates Belt 46/30
Pinion C1.9 Smart Shift CDX Gearbox
Hydr. Disc Brakes, 160 mm, Schimano | TRP
CNC Aluminium
Semi Matt Black Anodized
Desiknio Semi Matt Black Anodized Aluminium
Brooks C17 Carved
Ergon GA30
15 kg
MAHLE X20 Hub Motor
250 W
55 Nm of Torque
MAHLE iX250 Inner Battery
Panasonic 18650GA – 10S/2P
CAN BUS
250 Wh
*optional Range Extender MAHLE e185 | 171 Wh | max. 50 km extra
36 V
2 – 3 hours
< 50 Km
> 100 Km
25 Km/h
Schwalbe G-One ALLROUND 40-622
Front: Supernova V521s, 100 lx
Back: Supernova E3
